PRODUCT ADVANTAGE
1. High Precision: ±0.1g weighing error ensures consistent product loft and thermal performance.
2. High Efficiency: Single-unit production capacity reaches 300-800 pieces/hour (depending on product complexity).
3. Cost Savings: Reduces reliance on manual labor and increases down utilization rate to over 98%.
4. Adaptability: Supports diverse weight specifications, compartment designs, and down materials (duck down, goose down, etc.).
5. Eco-Friendly Operation: Closed-loop operation minimizes dust dispersion and enhances workshop cleanliness.
PRODUCT FEATURES
1. Fewer replenishments and more accurate refunds, enabling precise savings on down and cotton.
2. Independent weighing design to eliminate external interference.
3. Gate closing mechanism prevents down or cotton from spilling.
4. Compatible with both down and cotton, reducing redundant investment.
5. Automatic allocation for large-weight filling.
6. USB data import/export functionality.
7. Dual-frequency control drive for enhanced energy efficiency.
8. Dual photoelectric sensors for higher reliability.
9. Automatic blockage removal to save labor.
10. Constant humidity control system.
11. Motor protection against overcurrent, undervoltage, and overvoltage.
12. Built-in fan for space-saving.
Optional features: voice control, internet connectivity, barcode-scanning charging, and data streaming.
TECHNICAL PARAMETERS
Machine model | SP-9583RM10 | SP-9584RM10 | SP-9586RM10 | SP-9587RM10 | SP-9588RM10 | |
Filling port | 1 | 1 | 1 | 1 | 1 | |
Total cycles | 3 | 4 | 6 | 7 | 8 | |
Capable materials | Low pile, high pile, pearl cotton, foam cotton, hand cotton | |||||
Drive mode | Dual variable frequency drive | |||||
Mixing structure | Three-phase motor 0.75KW+RV63 reducer | |||||
Maximum display accuracy | 0.01g | |||||
Setting range | 320g | |||||
Down capacity per bucket | 30g | |||||
Cotton capacity per bucket | 35g | |||||
Outlet pipe diameter | Φ32mm | |||||
Filling speed | 5-16g/s | |||||
Supply voltage | Single phase 220VAC | |||||
Rated power | 2KW | |||||
Air pressure requirements | ＞0.6Mpa, 0.6m³/min | |||||
Host size | 1.4*0.6*2m | 1.75*0.6*2m | 2.03*0.6*2m | 2.3*0.6*2m | ||
Weighing box size | 1.2*0.6*0.9m | 1.69*0.6*0.9m | 1.97*0.6*0.9m | 2.24*0.6*0.9m | ||
Dust removal table size | 1*0.6*1.2m | |||||
Minimum floor area | 2*2.5m | 3*2.5m | ||||
PRODUCT USES
1. Production of down jackets/down pants
This is the core application scenario. In the industrial production of down jackets and down pants, automatic down filling machines can accurately fill down into the interlayers of different parts such as the body, sleeves, and hats according to preset parameters (such as down filling amount and position). They replace the inefficiency and errors of manual down filling, especially suitable for mass production of standardized products.
2. Production of down home textile products
• Down quilts: Filling down for down quilts of different specifications (single quilts, double quilts) and different蓬松度 (loft), ensuring uniform down filling in each grid to improve the warmth and comfort of the quilt.
• Down pillows/down cushions: Quantitatively filling down for small home textile products such as pillows and cushions, avoiding problems of uneven filling or excessive/insufficient filling caused by manual operation.
3. Production of outdoor products
Outdoor equipment such as down sleeping bags, down jackets, and down mountaineering suits have extremely high requirements for the accuracy of down filling (directly affecting warmth performance and weight). Automatic down filling machines can meet strict filling standards, ensuring the reliability of products in extreme environments.
4. Production of children's clothing and infant products
Children's down jackets, down vests, and other products need to strictly control the down filling amount (to avoid being too thick affecting movement or too thin reducing warmth). Moreover, high cleanliness is required during the filling process. The密封性 (sealing performance) and precision of automatic down filling machines can reduce the mixing of impurities, meeting the safety standards for infant products.
5. Processing of customized down products
For the high-end custom market (such as custom down quilts and personalized down jackets), automatic down filling machines can flexibly meet different customers' personalized needs for down filling amount and loft by adjusting parameters, balancing customization and production efficiency.
6. Filling of industrial thermal insulation materials
In some industrial scenarios, down is used in special thermal insulation materials (such as pipeline insulation sleeves and equipment heat insulation layers) due to its light weight and strong warmth retention. Automatic down filling machines can realize quantitative filling of such industrial products, improving the stability of insulation effects.
7. Mass production in e-commerce/small processing plants
With the rise of e-commerce live streaming and small-batch quick response modes, small and medium-sized processing plants need to quickly respond to orders. Automatic down filling machines (especially small and easy-to-operate models) can reduce labor costs and improve the efficiency and consistency of small-batch production.
PRODUCT VIDEO
FAQ
Q1. What is the filling accuracy of the automatic down filling machine?
A1: The machine uses high-precision weighing sensors and advanced control systems, achieving a filling accuracy of ±0.1g, which meets the production needs of products requiring precise down filling.
Q2. Is the equipment difficult to operate?
A2:Operation is simple and user-friendly. The machine features a humanized interface: input parameters (e.g., filling weight) on the control panel and start the process with one button. It also includes an operation guide and fault prompt function, enabling quick上手 for beginners.
Q3. How about daily maintenance? Any precautions?
A3: Maintenance is easy. Regularly clean residual down from the surface and interior to prevent blockages; check for loose component connections; lubricate moving parts monthly. Note: Always power off the device before cleaning to avoid accidents.
Q4. What if the machine malfunctions?
A4: The built-in fault diagnosis system triggers an alarm with error codes. Troubleshoot初步 using the manual. If unresolved, contact our 24/7 after-sales technical support team. On-site maintenance by professionals is available when necessary.
