PRODUCT ADVANTAGE
1. Machine returns back to original position once fabric runs empty.
2. The machine power will automatically shut off upon 5 minutes idle.
3. The spread laid fabric is not pulled when the emergency stop triggers.
4. The streamline shape can reduce the wind disturbance, noise and vibration
5. Automatic fabric expanding system.
6. PLC touch panel, user-friendly operation system.
7. Non-tension spreading.
8. Simple operation increases production efficiency and also ensures the best quality.
9. The new Arc mechanism ensures the elastic fabrics expanded perfectly.
TECHNICAL PARAMETERS
Model | KW-190 | KW-210 |
Power supply | 1P/220V | |
Motor | 1KW | |
Maximum cloth width | 1900mm/75” | 2100mm/83” |
Table width | 2130mm/84” | 2330mm/92” |
Machine weight | 340kg | 360kg |
Weight of cloth roll | 60kg max | |
Diameter of cloth roll | 450mm max | |
Travel speed | 90m/min max | |
Machine dimensions | 2600*1800*950mm | 2800*1800*950mm |
Packing dimensions | 2800*2000*1250mm | 3000*2000*1250mm |
N.W/G.W | 570/860kg | 610/970kg |
Spreading height | One way 220mm, 300mm(KW-H) Face to face 150mm, 230mm(KW-H) | |
Spreading methods | One-way spreading (face up) Zigzag spreading (face to face) Multiple length spreading (face up) | |
PRODUCT USES
- Flat fabric laying before bulk cutting in garment factories
- Automated stacking of composite materials for automotive interiors
- Precision laying of non-woven fabrics for medical protective clothing
- Efficient handling of elastic fabrics in sportswear production
- Pre-forming lightweight fabrics for aerospace applications
PRODUCT VIDEO
FAQ
Q1: The fabric shifts or wrinkles during operation. What could be the cause, and how to resolve it?
A1:
Possible causes:
- Uneven fabric tension or improper alignment;
- Low sensor sensitivity or calibration errors;
- Debris or wear on the conveyor belt or pressure rollers.
Solutions:
1. Re-align the fabric to ensure it is flat and free of tangles;
2. Clean the sensors and recalibrate them;
3. Inspect the conveyor belt/rollers, remove debris, or contact support to replace worn parts.
Q2: What regular maintenance does the automatic fabric spreader require?
A2:
Recommended maintenance:
- Daily: Clean the work surface, remove fabric debris, and check sensor responsiveness;
- Weekly: Lubricate guide rails and transmission components, inspect belt tension;
- Monthly:Calibrate spreading accuracy, check motor and circuit stability;
- Annual: Schedule a full inspection with the manufacturer to replace consumables (e.g., worn rollers).
Q3: What fabric types are compatible with the machine? Are there thickness limitations?
A3:
- Supported fabrics: Woven, knitted, non-woven, and similar materials;
- Thickness limits:Typically handles fabrics between 0.1mm–3mm (varies by model). Excessively thick or highly elastic fabrics may cause uneven spreading. Test beforehand or consult the manufacturer.
Q4: The machine suddenly stops and triggers an alarm. How to troubleshoot?
A4:
Steps:
1. Check the control panel for error codes (e.g., E01/E02) and refer to the manual to identify the issue (e.g., motor overload, sensor failure);
2. Power off the device and check for fabric jams or blockages;
3. Restart the machine. If the alarm persists, note the error code and contact technical support.
Q5: How to adjust the spreading length and layers? Is professional training required?
A5:
- Input parameters (length, layers) via the control panel. Some models support preset software templates;
- First-time users should follow the manual or request manufacturer training to avoid misconfiguration;
- For complex tasks (e.g., patterned spreading), consult a technician.
