PRODUCT ADVANTAGES
1. High-Precision Weighing System
- Equipped with high-sensitivity sensors and a PLC intelligent control system, achieving a filling accuracy of ±0.01 grams to meet the stringent requirements of heavyweight home textile production.
- Supports multi-stage filling modes, adapting to varying weight specifications of products to prevent underfilling or material waste.
2. Highly Adaptive Design
- Compatible with diverse filling materials such as down and synthetic fiber cotton, ensuring stable filling even for materials with significant differences in fluffiness.
- Modular structure allows customization of the number of filling heads (single/multi-head) and nozzle diameters to accommodate different product types like quilt cores and pillow inserts.
3. Energy Efficiency & Eco-Friendliness
- Features a closed filling system combined with a negative-pressure recovery device, effectively reducing airborne fiber pollution and improving workshop air quality.
- Powered by low-energy-consumption motors with minimal operational noise, complying with green manufacturing standards.
PRODUCT FEATURES
1. More refunds and less replenishment, precisely saving down and cotton.
2. Independent weighing to eliminate interference.
3. Gate closure to prevent down or cotton rolling.
4. Automatic allocation of large weight.
5. USB data import and export.
6. Variable frequency drive saves more power.
7. Automatic blockage removal and labor saving.
8. Capable for down and cotton to reduce repeated investment.
9. Motor over-current, under-voltage and over-voltage protection.
Optional: voice function, internet function, code scanning charging and data stream.
PRODUCT PARAMETERS
Machine model | SP-9264M10 |
Filling port | 1 |
Total cycles | 4 |
Filling materials | Low pile, high pile, pearl cotton, foam cotton, hand cotton |
Drive mode | Single variable frequency drive |
Mix structure | Three-phase motor 0.75KW+RV63 reducer |
Maximum display accuracy | 0.01g |
Setting range | 320g |
Down capacity per bucket | 100g |
Cotton capacity per bucket | 120g |
Filling port diameter | Φ38 to 50mm |
Filling speed | 5-30g/s |
Supply voltage | Single phase 220VAC |
Rated power | 2KW |
Air pressure requirements | ＞0.6Mpa, 1m³/min |
Host size | 2*1*1.9m |
Minimum floor area | 2*2.5m, about 5㎡ |
PRODUCT USES
Widely applicable to the production of heavyweight home textile products such as down quilts, thick mattresses, sofa cushions, and pet beds, it is particularly suitable for medium-to-large-scale home textile manufacturers, down product processing factories, and OEM/ODM facilities.
