PRODUCT ADVANTAGES
1. High-Efficiency Precision Filling
- Weight accuracy of ±0.1g, filling speed of 300-500 kg/h. Daily output: 500-800 down comforters per machine (varies by specifications).
- 3D uniform filling technology eliminates clumping, ensuring ≥98% fluffiness consistency.
2. Smart Adaptability
- Supports hybrid filling with down, fiberfill, and functional batting (e.g., antimicrobial/mite-proof materials).
- Accepts single-piece orders and switches product parameters (weight, zoning, size) in 3 minutes.
3. Safe & Eco-Friendly Production
- Closed-loop filling system + scattered down recovery, reducing material loss to ≤0.1%.
- CE-certified with ATEX-compliant dust explosion-proof modules and operational noise <65 dB.
4. Simplified Operation & Maintenance
- User-friendly graphical touchscreen interface (master basic functions in 30 minutes).
- Modular design enables quick replacement of wear-prone parts (filters, suction tubes).
Features
1. More refunds and less replenishment, precisely saving down and cotton.
2. Independent weighing to eliminate interference.
3. Gate closure to prevent down or cotton rolling.
4. Automatic allocation of large weight.
5. USB data import and export.
6. Variable frequency drive saves more power.
7. Automatic blockage removal and labor saving.
8. Capable for down and cotton to reduce repeated investment.
9. Motor overcurrent, undervoltage and overvoltage protection.
Optional: voice function, internet function, code scanning charging and data stream.
PARAMETERS
Machine model | SP-9264M10 |
Filling port | 1 |
Total cycles | 4 |
Filling materials | Low pile, high pile, pearl cotton, foam cotton, hand cotton |
Drive mode | Single variable frequency drive |
Mixing structure | Three-phase motor 0.75KW+RV63 reducer |
Maximum display accuracy | 0.01g |
Setting range | 320g |
Down capacity per bucket | 100g |
Cotton capacity per bucket | 120g |
Filling port diameter | Φ38 to 50mm |
Filling speed | 5-30g/s |
Supply voltage | Single phase 220VAC |
Rated power | 2KW |
Air pressure requirements | ＞0.6Mpa, 1m³/min |
Host size | 2*1*1.9m |
Minimum floor area | 2*2.5m, about 5㎡ |
PRODUCT USES
Premium Down Comforter Production:
Precise control of down filling density (5-3000g/m²), adaptable for full product ranges from summer quilts to extreme cold-weather comforters.
FAQ
Q1: What the home textile automatic filling machine do?
A1:
- Precision filling for down comforters, pillows, etc., with a weight accuracy of ±0.1g and a daily output of 500-800 comforter cores.
- Hybrid filling (down + fiberfill/antibacterial materials) to prevent clumping, ensuring ≥98% fluffiness consistency.
Q2: Is it complicated to operate? How about maintenance?
A2:
- One-touch touchscreen operation – master basic functions in 30 minutes.
- Daily maintenance: Clean the filter screen and check air pressure. Wear-prone parts (e.g., suction tubes) can be replaced quickly.
Q3: Does it support small-batch customization?
A3:
- Accepts orders starting from 1 piece.
- Switch product parameters (weight, size, zonal filling) in 3 minutes.
Q4: Is the machine safe and eco-friendly?
A4:
- CE-certified with dust explosion-proof modules (ATEX compliant) and emergency stop buttons.
- ≤0.1% material loss and compatible with ≥30% recycled down for sustainable production.
