PR-1510C/1512C
PRIORITY
PRODUCT ADVANTAGES
1. High-Efficiency Multi-Layer Cutting: Capable of cutting 1-5 layers of templates (up to 8mm thickness) in a single pass, significantly enhancing production efficiency.
2. High Precision and Stability: Features a CNC machine tool-standard frame design combined with a scientific mechanical clamping system, ensuring vibration-free operation and smooth, precise curve processing.
3. Intelligent Software Support: Equipped with the Gold Partner Kimo2016 Template Software, enabling code-free operation to simplify programming and achieve rapid pattern generation and cutting.
4. Multi-Functional Tool System: Includes template-specific column cutters, spiral blades, sharp knives, and special milling cutters, supporting both cutting and engraving for complex pattern processing.
5. High-Speed Water-Cooled Variable-Frequency Spindle: Utilizes water-cooling technology to ensure stability during prolonged operation, with a maximum cutting speed of 600mm/s (adjustable based on material).
PRODUCT FEATURES
1. Maximum cutting size: 1500*1000mm, 1500*1200mm
2. Accept the bespoke specifications, the maximum cutting size can be 3000*1600mm
3. Can once cut 8mm thickness within 1-5 layers template
4. Gold partner kimo 2016 template software
5. High speed, precision, no code, curve smooth without shaking
6. Spindle motor: water-cooled frequency conversion
7. Material fixed way: science and stability of mechanical clamping
8. Frame platform design and manufacture according to the standard of numerical control machine tool
9. Cutting way: template specific column knife, spiral blade, sharp knife and special milling cutter optional, have both cutting and engraving function
10. Tool specification: 3.175mm, 4.175mm
11. Maximum cutting speed: 600m/s (according to different cutting materials)
12. Cutting material: PVC board, acrylic board, MDF board, plastic board and other materials
13. Drive way: step system
14. Transmission port: serial port
15. Power supply: 50/60Hz, 110/220V, 2.4KW
PRODUCT ADVANTAGES
1. High-Efficiency Multi-Layer Cutting: Capable of cutting 1-5 layers of templates (up to 8mm thickness) in a single pass, significantly enhancing production efficiency.
2. High Precision and Stability: Features a CNC machine tool-standard frame design combined with a scientific mechanical clamping system, ensuring vibration-free operation and smooth, precise curve processing.
3. Intelligent Software Support: Equipped with the Gold Partner Kimo2016 Template Software, enabling code-free operation to simplify programming and achieve rapid pattern generation and cutting.
4. Multi-Functional Tool System: Includes template-specific column cutters, spiral blades, sharp knives, and special milling cutters, supporting both cutting and engraving for complex pattern processing.
5. High-Speed Water-Cooled Variable-Frequency Spindle: Utilizes water-cooling technology to ensure stability during prolonged operation, with a maximum cutting speed of 600mm/s (adjustable based on material).
PRODUCT FEATURES
1. Maximum cutting size: 1500*1000mm, 1500*1200mm
2. Accept the bespoke specifications, the maximum cutting size can be 3000*1600mm
3. Can once cut 8mm thickness within 1-5 layers template
4. Gold partner kimo 2016 template software
5. High speed, precision, no code, curve smooth without shaking
6. Spindle motor: water-cooled frequency conversion
7. Material fixed way: science and stability of mechanical clamping
8. Frame platform design and manufacture according to the standard of numerical control machine tool
9. Cutting way: template specific column knife, spiral blade, sharp knife and special milling cutter optional, have both cutting and engraving function
10. Tool specification: 3.175mm, 4.175mm
11. Maximum cutting speed: 600m/s (according to different cutting materials)
12. Cutting material: PVC board, acrylic board, MDF board, plastic board and other materials
13. Drive way: step system
14. Transmission port: serial port
15. Power supply: 50/60Hz, 110/220V, 2.4KW
